9kv Porcelain Surge Arrester

FOB Reference Price:Get Latest Price
US $1-100 / Pieces | 500 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
BONLE
Model Number:
Y5W-9
Material:
Porcelain
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton
Port
FUZHOU
Lead Time :
30-45DAYS



9kv Porcelain Surge Arrester



ZnO lightning arrester is one kind of most advanced over-voltage protector at present due to its core components of resistance applying ZnO and other metal oxide to make of comparing with traditional carborundum arrester, it improves greatly V-A charcateristics of resistance,increases the getting through ability of resistance,thereby it brings fundamental,change to features of arrester.

Under normal working voltage.The current passing arrester only A class,when bearing over voltage.The excellent non-linear V-A features of arrester would make effect,the current passing through the arrester increase high to thousands of Ampere instant the arrester is under getting through state,to release over-voltage energy therefore it effective limits the damage to power transmission equipments due to over voltage.



Main technical parameters:

Model  TypeRated  Voltage/kVMCOV/kVSteep  Current  ImpulseSwitching  Current  ImpulseLightning  Current  Impulse2000s  Square  Wave  Impulse  Current  Withstand4/10  S  High  Current  Impulse/kV
HY5W-332.559.57.7910065
HY5W-665.119.515.41810065
HY5W-997.6528.523.12710065
HY5W-10108.436302315065
HY5W-11119.440333015065
HY5W-121210.23830.83610065
HY5W-151512.747.538.54510065
HY5W-181815.35746.25410065
HY5W-21211766.553.96310065
HY5W-242419.27661.67210065
HY5W-272721.985.569.38110065
HY5W-303024.49576.59010065
HY5W-333326.8104.584.79910065
HY5W-36362911492.410810065
HY5W-424234.1132.3100.112610065
