Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: BONLE
  • Model Number: 56-1
  • Type: Insulator
  • Material: Porcelain, pocelain
  • Application: High Voltage
  • Tensile Strength: 11KN
  • type: pin

Packaging & Delivery

Packaging Details: WOODEN CASE OR EXPORT CARTON
Delivery Detail: 30-45days

ANSI 56-1 Porcelain Pin Insulator

ANSI Class56-1
Creepage Distance, mm330
Dry-arcing distance,mm152
Min.pin length, mm127
Cantilever Strength, kn11
Power Frequency Flashover VoltageDry, kv95
Wet, kv60
Critical Impulse Flashover VoltagePos., kv150
Neg., kv190
Power Frequency Puncture Voltage,kv130
Test Voltage to Ground, kv15
Maximum RIV at 1000KHZ, μv100
